Cleaning and Refueling for Spindles.

1.Inner Side of High Precision Filter

2.Outside of High Precision Filter

3.Cleaning and Refueling Nozzel

4.Electrical Motor Pump

5.Pressure Gauge

6.Oil Filter

1.Effective Cleaning

Works based on the negative pressure so the fuel injection quantity is large, and the cleaning of inner tube is thorough because the extraction and injection works concurrently.

2.Simple and Fast

Only requires one man to finish the cleaning and refueling process using one oil tank and one nozzle, the whole operation is simple and fast.

3.Effective

The refueling is fast and effective, each spindle takes only 3-5 seconds.

4.High Safety Coefficient

Using pure negative pressure source, the operation is safe and no need to pre-rising or adjust pressure, and eliminated the possibilities of tube burst and oil blow.

5.Stable Performance and Low Maintenance Cost

The main body is durable in use and uniquely designed and made by steel parts, the performance is stable and the maintenance cost is low because of minimum use of quick-wear parts.

6.Oil Saving and Environment Friendly

The used oil is recyclable after filtration through high precision strainer, the consumption of oil is low which saves use cost and more environment friendly.

7.Wide Application Range

You Lian’s patented products were built according to the using habit of domestic textile customers and widely applied.

This machine is suitable for inner tube cleaning and refueling on high speed pin roller bearing spindles that applies to textile equipment, includes spinning machine、yarn twisting machine、twisting machine etc,.
